Principle:
The QG series pulse air flow dryer is a large-scale drying equipment that adopts the principle of instantaneous drying. It uses the rapid movement of heat carrying air to drive wet materials and suspend them in the hot air. This strengthens the entire drying process and improves the speed of heat and mass transfer. The non bound moisture of the materials dried by air flow can be almost completely removed, and the dried materials will not produce deterioration. The output can be significantly improved compared to general drying machines, and users can achieve high economic benefits in the short term.
Suitable materials:
This type of equipment is suitable for a wide range of materials. In addition to the materials mentioned in the basic model, there are also: A. B.C intermediates, A.B.S resins A．S．C、 White carbon black, benzothiazolone, tea meal, oxalic acid catalyst, promoter m.d.m, catalyst, precipitated carbon powder, acetaminophen, p-aminosalicylic acid, Doraemon, phthalic acid, diethylammonium, titanium dioxide, activated carbon, sodium fluorosilicate, fluorite ore, silica gel powder, synthetic resin, calcium phosphate, polypropylene resin, aureomycin, sodium pyrosilicate, coffee grounds tetracycline, ferric oxide, calcium carbonate, corn protein, iron oxide, gypsum retarder, etc. Main recommendation: Used for drying wood flour, sawdust, rice bran, and bran; The above-mentioned materials have special characteristics: light density, difficult to add, flammable, and explosive. In response to this situation, our company's technical department has developed a new type of airflow dryer, which improves the feeding form on the basis of the original airflow dryer and solves the "bridging" phenomenon. Innovatively improved the cyclone separator, solving the problem of material rolling and not discharging. The system integration, control, and over temperature alarm interlock shut down the heat source, effectively solving the problem of combustion and explosion caused by high temperature.
