YPG series pressure spray (cooling) dryer-Changzhou Yufeng Drying Equipment Co., Ltd.

Brief description: the pressure type spray drying granulator uses the pressure type atomizer to atomize the solution or slurry materials into
Category: spray dryer
Detailed description:

Overview:
The pressure type spray drying granulator is a kind of equipment that uses the pressure type atomizer to atomize the solution or slurry materials into fine droplets with the help of the pressure of the diaphragm pump, so that the surface area can be significantly increased, and through full heat exchange with the hot air, it can be quickly dried (tens of seconds to tens of seconds), so as to obtain powder or fine particle products.

Feature:
●Fast drying speed, especially suitable for heat sensitive materials;
●The obtained product is spherical particles with uniform particle size, good fluidity and solubility, high purity, and good quality;
●It can be used for hot air drying, granulation, cooling granulation, spray crystallization, spray reaction, etc;
●It can be equipped with a fine powder return and wet agglomeration system to meet the user's requirements for material particle size.
●Simple and stable operation, easy control, and easy implementation of automated operations. The product particle size, bulk density, and water powder can be adjusted within a certain range

Application:
Suitable for liquids with corresponding fluidity in food, medicine, chemical, dyeing, ceramics, biochemistry, pesticides, plastics, etc.

Technical parameter table:

Model	50	100	150	200	300	500	1000
Water evaporation rate Kg/h	50	100	150	200	300	500	1000
External dimensions（Φ×H）mm	1600×8900	2000×11500	2400×13500	2800×14800	3200×15400	3800×18800	4600×22500
High pressure pump pressure Mpa	2-10
Power KW	8.5	14	22	24	30	82	30
Inlet air temperature ℃	300-350
Product moisture content %	﹤5(可达0.5)
Material recycling %	﹥97
Electrical heating KW	75	120	150	When the temperature is below 200 degrees, calculate according to actual conditions
Electric steam Mpa+KW	0.5+54	0.6+90	0.6+108
Hot blast stove Kcal/h	100000	150000	200000	300000	400000	500000	1200000

Note: Some parameters may be adjusted according to different materials during design, and the design shall prevail.
